2276cc LONG BLOCK – ALL NEW PARTS BUILD2021

The 2276cc Long Block is a long block engine from Automotive Remains LLC, built for air-cooled Volkswagen applications.

This 2276cc long block is built entirely from brand-new parts (no exchange required), with an option to build it as a turnkey engine. It’s based on an Autolinea magnesium crankcase (Super Race case available for cranks over 82mm), full-flowed with a remote twist-on oil filter, with an 8mm chromoly head stud kit, a forged counterweighted 8-dowel crankshaft dynamically balanced with the flywheel, a 200mm 12V lightened 8-dowel flywheel, and a 38mm heavy-duty chromoly gland nut. Standard spec includes chromoly I-beam 5.4 inch VW-journal con rods (H-beam upgrade available), an Engle W90-W125 camshaft kit with matched followers (steel straight-cut upgrade available), standard main and rod bearings, a 26mm oil pump, cast pistons and barrels (forged upgrade available), big-valve mild-port cylinder heads, a chromoly steel pushrod set, a bolt-up shaft rocker set (forged 1.25 ratio upgrade available), aluminum rocker covers, and a full Elring gasket kit. Refurbished gearbox options (stock, Freeway Flier, or Pro Street) are available. Contact us for full specification details.

2276cc long block built from brand-new parts on an Autolinea magnesium case, with a forged counterweighted crankshaft and an Engle camshaft kit. Turnkey build and gearbox options available.

2276cc Long Block Details

Volkswagen’s air-cooled flat-four engine powered the Beetle, Karmann Ghia, Bus, and Type 3 for decades, and it remains one of the most widely serviced engine platforms in the classic car hobby today. A long block typically includes the engine case, crankshaft, connecting rods, pistons and cylinders, and cylinder heads assembled as a complete unit, while a turnkey engine adds the components needed to run, such as the carburetor, ignition, and pulley.

Because these engines are mechanically simpler than modern water-cooled designs, many owners choose to replace a worn engine with a fresh 2276cc Long Block rather than rebuild it piece by piece. If you’re not sure which configuration is right for your vehicle, contact Automotive Remains LLC and our team can help you compare options before you order.

Why shop with us?

• Quality products at competitive prices
• Professional customer support
• Reliable shipping options
• International shipping available on all products
• Careful packaging to help ensure your order arrives safely

Browse our full selection of LONG BLOCKS – TYPE 1 for more options.

Automotive Remains LLC is based in Weeki Wachee, Florida, and specializes in air-cooled Volkswagen parts and engines. Contact us at info@automotiveremainsllc.com or call +1 760-879-0998 (Monday through Saturday, 9am to 5pm) with any questions about the 2276cc Long Block before you order.
